Maximum 200% PV input
Maximum 40A input current per MPpT, support high power solar panel
AI ready, forecasting solar generation and load consumption, smart energy management strategy*
VPP ready, SolaX cloud supports resource aggregator (2030.5, OpenADR )
Support smart scene function, intelligent loads management(e.g., Heat pump, EV charger)*
Micro-grid ready, supporting a variety of scenarios, both on-grid and off-grid, balancing power between PCS and Hybrid in real time
Support 7x24h scheduling mode
Support Wireless meter solution
Dual independent battery ports are ready to expand more capacity
Robust back-up ability, switch over time ＜10ms, up to 150% EPS output for 10s
Support off-grid operation
IP66 protection level
AC&DC SPD type II, always guarding the inverter
AFCI optional
Smart IV Curve scan for early panel diagnosis
It offers 24/7 smart energy management, utilizing AI to forecast solar generation and load consumption, with VPP readiness and intelligent scene functions for optimal energy use. It delivers high efficiency and reliability with a switch-over time of less than 10ms and up to 150% EPS output for 10 seconds, supporting off-grid operations. Additionally, it is highly cost-effective, supporting up to 200% PV input and 40A input current per MPPT, making it ideal for high-power solar panels and ensuring maximum energy savings and efficiency.
| Parameter | X3-AELIO-61K |
| Max. PV Input Power [kW] | 121 |
| Max. PV Input Voltage [V] | 1000 |
| Start-up Voltage [V] | 200 |
| Nominal Input Voltage [V] | 650 |
| MPPT Voltage Range [V] | 160-950 |
| No. of MPP Trackers / Strings per MPP Tracker | 6 (2 per MPPT) |
| Max. Input Current per MPPT [A] | 40 |
| Max. Input Short Circuit Current per MPPT [A] | 50 |
| Rated AC Output Power [kW] | 61 |
| Rated AC Output Current [A] | 88.4 |
| Max. AC Output Apparent Power [kVA] | 66 |
| Max. AC Output Current [A] | 101.7 |
| Nominal AC Voltage [V] | 3P4W, 400/230, 380/220 |
| Rated AC Grid Frequency [Hz] | 50 / 60 |
| Adjustable Power Factor Range | 1 (0.8 Leading ~ 0.8 Lagging) |
| THDi (Rated Power) [%] | < 3 |
| Battery Type | Lithium-ion |
| Battery Voltage Range [V] | 180 - 820 |
| Max. Charge/Discharge Current [A] | 160 (80x2) |
| EPS Output (with Battery) Peak Apparent AC Power [kVA] | 66 |
| Max. Output Continuous Current [A] | 100.3 |
| Switch Time [ms] | < 10 |
| Max. Efficiency [%] | 98 |
| European Weighted Efficiency [%] | 97.2 |
| Ingress Protection | IP66 |
| Operating Ambient Temperature Range [℃] | -35 ~ 60 |
| Max. Operating Altitude [m] | < 3000 |
| Relative Humidity [%] | 0 ~ 100 |
| Typical Noise Emission [dB] | < 70 |
| Dimensions (W×H×D) [mm] | 820×670 × 257 |
| Net Weight [kg] | < 105 |
| Cooling Concept | Smart air cooling |
| Communication Interfaces | RS485, CAN(BMS), CAN, USB, DI, DO, DRM |
| Display | LCD (optional) |
| Standby Consumption (Night) [W] | < 10 |
| Parameter | X3-AELIO-60K |
| Max. PV Input Power [kW] | 120 |
| Max. PV Input Voltage [V] | 1000 |
| Start-up Voltage [V] | 200 |
| Nominal Input Voltage [V] | 650 |
| MPPT Voltage Range [V] | 160-950 |
| No. of MPP Trackers / Strings per MPP Tracker | 6 (2 per MPPT) |
| Max. Input Current per MPPT [A] | 40 |
| Max. Input Short Circuit Current per MPPT [A] | 50 |
| Rated AC Output Power [kW] | 60 |
| Rated AC Output Current [A] | 87 |
| Max. AC Output Apparent Power [kVA] | 66 |
| Max. AC Output Current [A] | 100 |
| Nominal AC Voltage [V] | 3P4W, 400/230, 380/220 |
| Rated AC Grid Frequency [Hz] | 50 / 60 |
| Adjustable Power Factor Range | 1 (0.8 Leading ~ 0.8 Lagging) |
| THDi (Rated Power) [%] | < 3 |
| Battery Type | Lithium-ion |
| Battery Voltage Range [V] | 180 - 820 |
| Max. Charge/Discharge Current [A] | 160 (80x2) |
| EPS Output (with Battery) Peak Apparent AC Power [kVA] | 66 |
| Max. Output Continuous Current [A] | 100.3 |
| Switch Time [ms] | < 10 |
| Max. Efficiency [%] | 98 |
| European Weighted Efficiency [%] | 97.2 |
| Ingress Protection | IP66 |
| Operating Ambient Temperature Range [℃] | -35 ~ 60 |
| Max. Operating Altitude [m] | < 3000 |
| Relative Humidity [%] | 0 ~ 100 |
| Typical Noise Emission [dB] | < 70 |
| Dimensions (W×H×D) [mm] | 820 × 670 × 257 |
| Net Weight [kg] | < 105 |
| Cooling Concept | Smart air cooling |
| Communication Interfaces | RS485, CAN(BMS), CAN, USB, DI, DO, DRM |
| Display | LCD (optional) |
| Standby Consumption (Night) [W] | < 10 |
| Parameter | X3-AELIO-50K |
| Max. PV Input Power [kW] | 100 |
| Max. PV Input Voltage [V] | 1000 |
| Start-up Voltage [V] | 200 |
| Nominal Input Voltage [V] | 650 |
| MPPT Voltage Range [V] | 160-950 |
| No. of MPP Trackers / Strings per MPP Tracker | 5 (2 per MPPT) |
| Max. Input Current per MPPT [A] | 40 |
| Max. Input Short Circuit Current per MPPT [A] | 50 |
| Rated AC Output Power [kW] | 50 |
| Rated AC Output Current [A] | 72.5 |
| Max. AC Output Apparent Power [kVA] | 55 |
| Max. AC Output Current [A] | 83.3 |
| Nominal AC Voltage [V] | 3P4W, 400/230, 380/220 |
| Rated AC Grid Frequency [Hz] | 50 / 60 |
| Adjustable Power Factor Range | 1 (0.8 Leading ~ 0.8 Lagging) |
| THDi (Rated Power) [%] | < 3 |
| Battery Type | Lithium-ion |
| Battery Voltage Range [V] | 180 - 820 |
| Max. Charge/Discharge Current [A] | 160 (80x2) |
| EPS Output (with Battery) Peak Apparent AC Power [kVA] | 55 |
| Max. Output Continuous Current [A] | 83.6 |
| Switch Time [ms] | < 10 |
| Max. Efficiency [%] | 98 |
| European Weighted Efficiency [%] | 97.2 |
| Ingress Protection | IP66 |
| Operating Ambient Temperature Range [℃] | -35 ~ 60 |
| Max. Operating Altitude [m] | < 3000 |
| Relative Humidity [%] | 0 ~ 100 |
| Typical Noise Emission [dB] | < 70 |
| Dimensions (W×H×D) [mm] | 820 × 670 × 257 |
| Net Weight [kg] | < 100 |
| Cooling Concept | Smart air cooling |
| Communication Interfaces | |
| Display | LCD (optional) |
| Standby Consumption (Night) [W] | < 10 |
| Parameter | X3-AELIO-49.9K |
| Max. PV Input Power [kW] | 100 |
| Max. PV Input Voltage [V] | 1000 |
| Start-up Voltage [V] | 200 |
| Nominal Input Voltage [V] | 650 |
| MPPT Voltage Range [V] | 160-950 |
| No. of MPP Trackers / Strings per MPP Tracker | 5 (2 per MPPT) |
| Max. Input Current per MPPT [A] | 40 |
| Max. Input Short Circuit Current per MPPT [A] | 50 |
| Rated AC Output Power [kW] | 49.9 |
| Rated AC Output Current [A] | 72.3 |
| Max. AC Output Apparent Power [kVA] | 49.9 |
| Max. AC Output Current [A] | 83.2 |
| Nominal AC Voltage [V] | 3P4W, 400/230, 380/220 |
| Rated AC Grid Frequency [Hz] | 50 / 60 |
| Adjustable Power Factor Range | 1 (0.8 Leading ~ 0.8 Lagging) |
| THDi (Rated Power) [%] | < 3 |
| Battery Type | Lithium-ion |
| Battery Voltage Range [V] | 180 - 820 |
| Max. Charge/Discharge Current [A] | 160 (80x2) |
| EPS Output (with Battery) Peak Apparent AC Power [kVA] | 49.9 |
| Max. Output Continuous Current [A] | 72 |
| Switch Time [ms] | < 10 |
| Max. Efficiency [%] | 98 |
| European Weighted Efficiency [%] | 97.2 |
| Ingress Protection | IP66 |
| Operating Ambient Temperature Range [℃] | -35 ~ 60 |
| Max. Operating Altitude [m] | < 3000 |
| Relative Humidity [%] | 0 ~ 100 |
| Typical Noise Emission [dB] | < 70 |
| Dimensions (W×H×D) [mm] | 820 × 670 × 257 |
| Net Weight [kg] | < 100 |
| Cooling Concept | Smart air cooling |
| Communication Interfaces | RS485, CAN(BMS), CAN, USB, DI, DO, DRM |
| Display | LCD (optional) |
| Standby Consumption (Night) [W] | < 10 |
