Residential Batteries
TSYS-LD51
-
5.1 kWh
The TSYS-LD51 stands out with its innovative smart management system, featuring an easy-to-use LCD touchscreen for intuitive control. Additionally, the system supports remote diagnostics and updates, making maintenance effortless. With an IP40-rated protection, it ensures safe and dependable operation across different environments.
Product Advantage
The TSYS-LD51 offers various mounting options, including floor, wall, and stack installations, and supports scalability of up to 16 units in parallel. Its CTP (Cell-to-Pack) design optimizes space and energy density, delivering exceptional efficiency for reliable energy management.
High Performance
5.1~81.9 kWh wide capacity range
Max.100A/135 A charge /discharge current
Cycle life> 6000 cycles
Assured Reliability
IP40 ingress protection
LFP battery cell & high-performance processors
Smart Management
Remote fault diagnosis, upgrade and maintenance
Wide temperature tolerance
User-friendly LCD touchscreen for intuitive and easy interaction
Flexible Adaptability
Supports floor, wall, or stack mounting
Expandable to 16 units in parallel
CTP (Cell-to-Pack) design maximizes space and energy density for superior performance
Product Parameters
-
TSYS-LD51-
BATTERY MODULE
Battery type
LFP
Scalability
Max. 16 pcs pack in parallel
Operating voltage range
42.4~57.6 V
Peak output power
10.2 kW, 10s
Rated voltage
51.2 Vdc
-
GENERAL
Weight
42.8 ± 1 kg
Dimensions (W × H × D)
370 x 635 x 183 mm
Enclosure protection
IP40
-
